The Aerodyne 47 Sailboat
Specs & Key Performance Indicators
The Aerodyne 47, a fractional solent-rigged sloop was designed by Roger Martin and built in South Africa by Aerodyne Marine.
An Aerodyne 47. Note the Solent rig and club-footed inner jib.
Published Specification for the Aerodyne 47
Underwater Configuration: Shoal draft bulb keel & spade rudder
Hull Material: Composite
Length Overall: 46'7" (14.2m)
Waterline Length: 42'1" (12.8m)
Beam: 14'4" (4.4m)
Draft: 6'0" (1.8m)
Rig Type: Fractional solent-rigged sloop
Displacement: 25,370lb (11,532kg)
Designer: Roger Martin
Builder: Aerodyne Marine (South Africa)
Year First Built: 2001
Year Last Built: 2007
Number Built: 3 (The Aerodyne 47 pictured above, 'Pandora', was build #3)
Published Design Ratios for the Aerodyne 47
1. Sail Area/Displacement Ratio: 17.5
- Less than 16 would be considered under-powered;
- 16 to 20 would indicate reasonably good performance;
- Over 20 suggests relatively high performance.
2. Ballast/Displacement Ratio: 40.7
- Under 40: less stiff, less powerful
- Over 40: stiffer, more powerful
3. Displacement/Length Ratio: 152
- Under 100: Ultralight
- 100 to 200: Light
- 200 to 275: Moderate
- 275 to 350: Heavy
- Over 350: Ultraheavy
4. Comfort Ratio: 26.0
- Under 20 indicates a lightweight racing boat
- 20 to 30 indicates a coastal cruiser
- 30 to 40 indicates a moderate offshore cruising boat
- 40 to 50 indicates a heavy offshore boat
- Over 50 indicates an extremely heavy offshore boat
5. Capsize Screening Formula: 1.9
- Under 2.0 (the lower the better): Better suited for ocean passages
- Over 2.0: Less suited for ocean passages
read more about these Key Performance Indicators...
Summary Analysis of the Design Ratios for the Aerodyne 47
1. A Sail Area/Displacement Ratio of 17.5 suggests that the Aerodyne 47 will, in the right conditions, approach her maximum hull speed readily and satisfy the sailing performance expectations of most cruising sailors.
2. A Ballast/Displacement Ratio of 40.7 means that the Aerodyne 47 will stand up well to her canvas in a blow, helping her to power through the waves.
3. A Displacement/Length Ratio of 152, tells us the Aerodyne 47 is clearly a light displacement sailboat. If she's loaded with too much heavy cruising gear her performance will suffer to a degree.
4. Ted Brewer's Comfort Ratio of 26.2 suggests that crew comfort of an Aerodyne 47 in a seaway is similar to what you would associate with the motion of a coastal cruiser with moderate stability, which is not encouraging news for anyone prone to seasickness.
5. The Capsize Screening Formula (CSF) of 1.9 tells us that an Aerodyne 47 would be a safer choice of sailboat for an ocean passage than one with a CSF of more than 2.0.
